Mobile Power Distribution Unit 1200A

Call for Price

  • Safety Engineered to reduce access to energized parts
  • Everything you need in a consolidated, mobile space
  • Fully portable. Place on any flat surface
  • Instant Electric Room
  • Enclosed, Climate Controlled
  • Quick and Efficient Set-up/Teardown of Large Temporary Power Distribution

Great for Temporary Hospitals, Temporary Offices/Shelters, Emergency Response Centers, Crisis Response for Utility Outage, etc.

Download Flyer Here

Category:

Product Purchase Request - MDPU

Mobile Power Distribution Unit - 1200A
  • Date Format: MM slash DD slash YYYY
  • Describe jobsite needs

Specifications:

  • 8’6” tall by 20’2” long
  • 23’11” long including trailer hitch
  • 31’6” long from door flap to hitch
  • 8’4” deep
  • Mounting: Level Surface, dirt or concrete

Surface Mount Panelboard with: 18 Circuits, 400A, Fully Rated, 480Y/277V, 3P4W, Al Bus, 14k AIC, MLO

  • (1) 400A, Main Lugs Only
  • (1) 200A, 3P FD Branch Breaker
  • (4) 100A, 3P Branch Breaker
  • (1) 300A Adjustable Breaker
  • (1) Std. Bolted Al Ground Bar (Al/Cu Cable)
  • (1) Type 1 Enclosure

Surface Mounted Panelboard with: 42 Circuits, 400A, Fully Rated, 208Y/120V, 3P4W, Al Bus, 10k AIC, MCB

  • (1) 400A, 3P KD Main Breaker
  • (6) 30A, 2P BAB Branch Breaker
  • (8) 100A, 2P BAB Branch Breaker
  • (14) 1P BAB Branch Provision Only
  • (1) Std. Bolted Al Ground Bar (Al/Cu Cable)
  • (1) Type 1 Enclosure

Surface Mounted Panelboard with: 42 Circuits, 225A, Fully Rated, 208Y/120V, 3P4W, Al Bus, 10k AIC, MCB

  • (1) 400A, 3P KD Main Breaker
  • (1) 200A, 3P ED Main Breaker
  • (10) 20A, 1P BAB Branch Breaker
  • (4) 100A, 2P BAB Branch Breaker
  • (1) Std. Bolted Al Ground Bar (Al/Cu Cable)
  • (1) Type 1 Enclosure

Surface Mounted Panelboard: 24 Circuits, 400A, Fully Rated, 480Y/277V, 3P4W, Al Bus, 14k AIC, MLO

  • (1) 400A, Main Lugs Only
  • (8) 200A, 3P FD Branch Breaker
  • (1) Std. Bolted Al Ground Bar (Al/Cu Cable)
  • (1) Type 1 Enclosure

Dry Type Transformer with: 3 Phase, 225 kVA, 480 Primary Volts, 208Y/120 Secondary Volts, Aluminum Winding Material, 60 Hz, General Purpose, Vented

  • NEMA 2 Enclosure Type

Safety Switches with:

  • (1) Neutral/Ground Kit
  • (3) Heavy Duty Switch — 400A, Fusible, 3-Pole, 600 VAC, NEMA 1
  • (1) Heavy Duty Switch — 1200A, Fusible, 3-Pole, 600 VAC, NEMA 1
